SLIDING DOOR OPERATOR
Features:
Art. 1071.101/1071.102
* Superior microprocessor technology precisely controls the door wing’s running speed, travel distance, with beautiful operation curve
* Reliable guardian function: If detects illegal door opening attempt, the motor will enhance the force to make the door stay closed
* Pulling or pushing the door will not cause software scramble contributed by the close-loop control technology
* Permanent open/ lock/ partial open/exit only/ auto, 5 status available by remote control or 5 position key switch
* Superior safety care, reverse immediately against obstruction on door’s closing, and stop encountering obstacles on door’s opening
* Digital screen, button adjusting, easier for debugging
* Longer lifetime, more than 2 million failure-free test
|
Specifications |
1071.101 |
1071.102 |
||
|
Door type |
Single |
Bi-parting |
Single |
Bi-parting |
|
Door weight (max)(kg) |
1x120 |
2x90 |
1x180 |
2x150 |
|
Clear passage width(mm) |
600-2000 |
600～2500 |
600-2000 |
600～3000 |
|
Power voltage(VAC, Hz) |
220V, 50/60Hz |
220V, 50/60Hz |
||
|
Opening speed (adjustable) (mm/s) |
100-500 |
100-600 |
||
|
Closing speed (adjustable) (mm/s) |
100-450 |
100-550 |
||
|
Hold-opening time (adjustable)( s) |
1-30 |
1-30 |
||
|
Motor (VDC) |
24 |
24 |
||
|
Motor power (W) |
55 |
60 |
||
|
Consumption power(W) |
150 |
150 |
||
|
Working temperature(℃) |
-20~ +70 |
-20~ +70 |
||
HEAVY DUTY SLIDING DOOR OPERATOR
Art.1071.108
Features:
* Heavy duty capacity for 2x200kgs doors thanks to 36V motor
* Anti-drop off carriage wheel prevent the door from dropping from the guide rail
* European type guide rail, sound absorbing rail embedded in rubber mat, reducing the noise of carriage wheel on the rail.
* Replaceable 2nd rail for the carriage wheel, no need to detach all the track, extremely saving the maintenance cost
* Superior safety care, reverse immediately against obstruction on door’s closing, and stop encountering obstacles on door’s opening
Technical parameter:
|
Specifications |
1071.108 |
|
|
Door type |
Single |
Bi-parting |
|
Door weight (max)(kg) |
1x250 |
2x200 |
|
Clear passage width(mm) |
600-2000 |
600～3000 |
|
Power voltage(VAC, Hz) |
220V, 50/60Hz |
|
|
Opening speed (adjustable) (mm/s) |
150-500 |
|
|
Closing speed (adjustable) (mm/s) |
150-450 |
|
|
Hold-opening time (adjustable)( s) |
2-20 |
|
|
Motor (VDC) |
36 |
|
|
Motor power (W) |
85 |
|
|
Consumption power(W) |
150 |
|
|
Working temperature(℃) |
-20~ +70 |
|
|
Class of protection |
IP20 |
|
1071.108 PACKING
