Powerful Garage Door Opener Features:
*Soft start and soft stop, quiet and stable
*Automatic closing time setting
*Self-lock in closure position
*Manual release in case of power failure
*Electric limit switch setting guarantee the accurate lifting distance
*The reversal force encountering obstacles can be adjusted
*Automatically reverse to open against obstruction in closing
*Automatically stop against obstruction in opening
*Photocell ON/OFF options
*Alarm on maintenance request
*Courtesy LED light 3 minutes off delay
*Memory saving function against power failure
*Transformer overload protection
*Available for connection to safety beam sensor, pushbutton switch, battery backup
Powerful Garage Door Opener Technical parameter:
|
Specification |
1012.101A |
1012.101B |
|
Input voltage(VAC, Hz) |
200-240V/110-127V,50-60Hz |
|
|
Rated current(A) |
0.5 |
0.7 |
|
Rated power(W) |
65 |
100 |
|
Drive force(N) |
600 |
1000 |
|
Motor voltage(VDC) |
24 |
|
|
Operation speed(mm/s) |
160 |
|
|
Hold-open time(seconds) |
9 position,15s/position |
|
|
Radio frequency (MHz) |
433.92 rolling code |
|
|
Lifting distance/height(max) (m) |
2.4-5 |
2.4-5 |
|
Door measurement (max)(㎡) |
10 |
15 |
|
Lifting force (max) (kg) |
80 |
100 |
|
Length of rail track(max)(m) |
3.2 |
4 |
|
Base plate |
Metal |
Metal |
|
Drive mechanism |
Chain/belt |
Chain/belt |
|
Ambient temperature(℃) |
－20～+60 |
|
|
Revolution(rpm) |
65 |
|
|
Protection (IP) |
20 |
|
|
Remote distance (max) m(ft) |
90 |
|
