2053.501 Wireless metal touch switch
Wireless Metal Touch Switch Features:
1. Frequency hopping design, improve anti-interference ability, effectively solve multiple identification problems.
2. Touch switch design, replace mechanical switch, longer service life.
3. When the signal is received, the light indication can confirm whether the signal switching is effective.
Wireless Metal Touch Switch Technical data： | |
Model | 2053.501 |
Support function | Touch sensing |
Stand-by current | ≤10μA |
Average emission current | 12mA |
Battery life | 22000 times |
Working humidity | ≤90% |
Ambient temperature | -30°C- 50°C |
Launch frequency | 2.4GHZ |
Battery | 2032 button battery 3V 2 pcs |
Installation method | Wireless |
Wireless distance | 38m |
Product size | 60mmx 16. 5mm |
Receiver technical parameters | |
Power supply | DC12~30V |
Stand-by current | 30mA (DC12V) |
Working current | 74mA (DC12V) |
Relay contact | 1A 24VDC |
Contact closing time | 1 .5s(jog) |
Signal output | Jog / hold / dial |
Product size | 110mm (L) x30mm (W) x 15mm (H) |
