2053.501Q Automatic door switch
Automatic Door Switch Features:
1. Touch switch design, replace mechanical switch, longer service life.
2. The transmitter adopts low power consumption design, and the battery life is longer.
3. It is widely used in various automatic door opening and door control devices.
Automatic Door Switch Technical data： | |
Model | 2053.501Q |
Support function | Touch sensing |
Stand-by current | ≤10μA |
Average emission current | 12mA |
Battery life | 3000 times |
Working humidity | ≤90% |
Ambient temperature | -30°C - 50°C |
Launch frequency | 2.4GHZ |
Battery | 2032 button battery 3V 2 pcs |
Installation method | Wireless |
Wireless distance | 38m |
Product size | 60mmx 16.5mm |
Receiver technical parameters | |
Power supply | DC12~30V |
Stand-by current | 30mA (DC12V) |
Working current | 74mA (DC12V) |
Relay contact | 1A 24VDC |
Contact closing time | 1 .5s(jog) |
Signal output | Jog / hold / dial |
Product size | 110mm (L) x 30mm (W) X 15mm (H) |
