Features
*Strong Spatial Adaptability
The door body can fully retract to one side, saving space and making it suitable for irregular door openings or environments with limited space.
*Flexible Opening Adjustment
The telescopic design allows for on-demand adjustment of the opening width, ideal for locations requiring frequent changes in passage dimensions.
*Sealing and Protection
The overlapping panel structure enhances windproof, dustproof, and waterproof performance, making it suitable for harsh environments.
*Silent Operation and Low Maintenance
With no physical friction, the operating noise is below 40 dB, and there is no need for regular replacement of rollers or lubrication components.
*Smart Control
Integrated sensors and a microprocessor support functions such as obstacle detection, automatic start/stop, and remote control.
1071.107B(pro)
1071.107C
Standard
SL107.01
Power unit
SL107.RT07
Remote control
SL107.02
Bolt lock
SL107.03
Frame-door hanging parts
How the Maglev Telescoping Door Operator (Art. 1071.107) Achieves Levitation and Glide
The system utilizes a magnetic drive mechanism where the roller bar incorporates permanent magnets, while the track houses a linear motor (acting as an electromagnet). When an operational signal is detected-via manual input, remote control, or motion sensor-current flows through the linear motor, generating a controlled magnetic field.
This field dynamically alternates between north and south poles, creating a repulsive and attractive force that propels the roller bar. The result is a frictionless, non-contact suspension state, allowing the door to levitate and glide with exceptional smoothness and quietness.
Technical parameters
|
Model |
1071.107B(pro) |
1071.107C |
|
Door leaf weight(kg) |
100-250 |
50-500 |
|
Track length(mm) |
1000-12000 |
1500-12000mm |
|
Passage width(mm) |
500-3000 |
750-3000 |
|
Opening speed |
200-500mm/s |
|
|
Closing speed |
200-500mm/s |
|
|
Hole-opening time |
0-30s |
|
|
Rated power |
120W(Pro:300W) |
300W |
|
Manual-open force |
10N |
|
|
Closing force |
≤10N |
|
|
Ambient temperature |
-40℃-60℃ |
|
|
Motor size(mm) |
47.6(W)*63.3(H) |
70(W)*82(H) |
Maglev telescoping sliding door operator Art.1071.107 Application Scenarios
Industrial and Logistics: Warehouses, garages, and logistics channels (scenarios requiring a large opening but with space constraints).
Commercial Buildings: Back doors of shopping malls and restaurant kitchens (requiring flexible isolation without affecting operational space).
Residential Courtyards: Villa courtyard doors and balcony doors (balancing aesthetics with space savings).
Special Environments: Cleanrooms and laboratories (locations requiring sealing and dust prevention).
