Japanese Type Sliding Door Operator Features:
* Advanced microprocessor technology and precise control system, provide good users' experience
* With a five-digit digital display and superior cutting-edge technology, the controller can detect the door leaf's condition quickly and accurately
* Easy to install and bebug, very user friendly
* Unique double-door interlock function realizes half-opening and full-opening
* 5 status can be chosed by switch according to user's needs: permanent open/ lock/ partial open/ exit only/ auto
* Powerful brushless square motor, high efficiency, high speed, high torque, continuous use without heating, much better than traditional AC servo motor
* High-performance power input can realize automatic regulation
* Overvoltage and overcurrent protection ensure high security
* In case of powerfailure, the door can be opened manually
* Longer lifetime, pass more than 2 million failure-free tests
Japanese Type Sliding Door Operator Technical parameters:
|
Door weight (single) |
1*130kgs |
|
Door weight (double) |
2*120kgs |
|
Door leaf width |
600~1500mm |
|
Opening speed |
150~550mm/s (adjustable) |
|
Closing speed |
150~550mm/s (adjustable) |
|
Motor details |
24V 80W 2300rpm |
|
Holding time |
0~60s (adjustable) |
|
Voltage |
AC90V~240V 50~60Hz |
|
Operating temperature |
-10℃~70℃ |
