Why Choose the 1022.102 swing gate opener?
The 1022.102 combines heavy-duty performance with user-friendly features. Its mechanical screw drive guarantees stability, while the flexible voltage options (AC/DC) allow for seamless integration into any electrical environment. Upgrade your entrance security and convenience today with the 1022.102 Swing Gate Opener.
1022.102 swing gate opener feartures:
I. Core Performance: Smooth, Quiet, and EfficientPrecision Screw Drive Mechanism: Utilizes a high-quality mechanical thread pole transmission to ensure the gate moves smoothly without jitter. This structure significantly reduces wear and tear compared to standard hydraulic systems. Ultra-Quiet Operation: Engineered for silence, the unit operates at ≤56dB, ensuring that gate movements do not disturb the peace of your home or workplace. High Efficiency: Available in 150W (AC) and 100W (DC) models, capable of driving gate leaves up to 3 meters wide. Opening times range from a swift 10 seconds (DC model) to a steady 19 seconds (AC model). All-Weather Durability: Built with an IP44 protection rating, resisting dust and water splashes. It operates flawlessly in extreme temperatures ranging from -45°C to +65°C. II. Intelligent Safety & User-Friendly DesignExternal Mechanical Limit Switch (New Feature): The mechanical limit blocks are strategically located underneath the motor's straight arm. This innovative design allows for easy adjustment without removing the cover, making installation and debugging significantly faster and more convenient. Reliable Limit Control: Equipped with NC/NO mechanical limit switches to ensure precise stopping positions, preventing over-travel and protecting the gate structure. Power Failure Release: In the event of a power outage, the integrated clutch can be easily released, allowing the gate to be opened and closed manually for uninterrupted access. Flexible Configuration: Supports both single and double gate control setups. An optional brushless motor is available for users seeking higher energy efficiency and extended lifespan. III. Structural AdvantagesExternal Control Box: Keeps the main operator unit compact while housing the control logic in a separate, accessible box for easier maintenance. Versatile Application: Ideal for various environments including private villas, factories, and industrial parks. |
  |
|
Technical parameter:
|
Specifications |
1022.102 |
1022.102D |
|
Gate width/leaf(m) |
3 |
|
|
Gate weight/leaf(kg) |
400~1000 |
|
|
Power supply(V) |
120/230AC |
24DC |
|
Power(W) |
150 |
100 |
|
Revolution(rpm) |
1400 |
|
|
Stroke length(mm) |
500 |
|
|
Opening time (s) |
19 |
10 |
|
Max cycles/hour |
40 |
60 |
|
Limit switch |
Mechanical(NC/NO) |
|
|
Noise(dB) |
≤56 |
|
|
Protection (IP) |
54 |
|
|
Environment temperature(℃) |
-45~+65 |
|
