Intelligent Residential Automatic Swing Door Operator
Irreversible Underground Swing Door Operator
Base box made of stainless steel
Heavy-duty lid and base with drainage holes
Gears made entirely of steel and brass
Waterproof motor IP67
All stainless steel with drain holes
|
Specifications |
Light-Swing 1093.1830 |
||
|
Door width(max)inch(mm) |
39.4"(1200) |
Opening speed |
250~450mm / sec |
|
Door weight(max)lbs. (kg) |
220(100) |
Closing speed |
250~450mm / sec |
|
Product dimensions inch(mm) |
20.3"×3.7"×3.5(515×95×90) |
Opening/closing time(sec.) |
3~7 |
|
Product weight(kg) |
6.5 |
Hold-open time(sec.) |
1~30 |
|
Output torque(N.m) |
65 |
Ambient temperature(℃) |
-20~+55 |
|
Motor power(W) |
50 |
Protection class |
IP41 |
|
Power standby(W) |
<2 |
Co5mpression force on the door |
By switch |
|
Power Required(VAC,Hz) |
110/220,50/60 |
Left/right hand setting |
By switch |
|
Rated current(A) |
<1 |
Push &Go function |
★ |
|
Power Output(max)(VDC mA) |
12,500 |
Protection against obstruction |
★ |
|
Shaft opening angle(°) |
45~135 |
||
