Automatic Collapsible Door , Stainless Steel

AUTOMATIC EXTENSION DOOR The automatic extension door is handed over by the principle of parallelogram, which is flexible. It features the best propulsion design and infrared anti-collision function, and has a manual clutch that can be manually opened and closed during a power outage. The automatic extension door is a telescopic shed type, which has the characteristics of stable opening and closing, seeing the door body, and occupying a small space after opening.

Send Inquiry

Description

Technical Parameters

AUTOMATIC EXTENSION DOOR

Automatic Collapsible Door , Stainless Steel Features:
*Aluminum/Stainless/Metal powder coating
*The best advancing design
*Electrophoresis process, colors bright, strong adhesion, non-fading, anti-oxidation
*Manual release on power stop
*Electronic buffering and infrared anti-collision function
*Each door is designed to customer's requirements

Automatic Collapsible Door , Stainless Steel Technical parameter:

Specification	1043.201
Input voltage(VAC, Hz)	150~260, 50
Power(W)	370
Motor rotation(rpm)	1400
Output rotation(rpm)	46.6
Output Torque(N.m)	100
Starting current(A)	≤3.5
Door height (m)	1.6
Door width (m)	0.6
Ambient temperature(ºC)	-20~+55
